Access Overview

Feature Overview

Item	Content
Applicable Roles	Operators
Navigation Path	AI Infra(On-Cloud) > Access Workbench > Access Overview
Page Route	/infrahub/op/workbanch/overview
Managed Objects	Access foundation, operational resource checklist, and authorization status

Beginner Explanation

Access Overview is a dashboard for cloud access readiness. It combines platforms, pools, accounts, deployment assets, and both authorization types so that missing prerequisites are visible.

Terminology

Term	Description
Access Foundation	A summary of connected cloud platforms, resource pools, and accounts.
Operational Resource Checklist	Readiness of runtime images, frameworks, models, and policies.
Authorization Status	A summary of tenant-cloud and business-region authorization.

Recommended Operation Order

Review Access Foundation, then the operational resource checklist, and finally both authorization areas. Open the responsible object page for each missing item.

Beginner Checklist

Scenario	Do First	Do Not Do Directly
First visit	Review existing objects, states, and available actions	Change an unknown object
Before a change	Verify upstream dependencies, impact scope, and target object	Skip dependency and impact checks
After completion	Validate the current and downstream pages with Result Validation	Rely only on a success message
Page error	Record the redacted object, time, and page message	Submit repeatedly or record real credentials

Prerequisites

1. The current account has the permission required for Access Overview.
2. The current account can view Access Overview and its linked detail pages.
3. Use the overview to assess status. Make changes on the responsible object page and return to validate.

Page Description

The upper area shows the access foundation, the middle area shows operational resources, and the lower area shows authorization status and management entries.

Page screenshots:

The image shows Access Overview page. Verify the target object, current state, fields, and actions.

Main Operations

View Access Overview

1. Go to AI Infra(On-Cloud) > Access Workbench > Access Overview.
2. Verify connected platform, pool, and account counts.
3. Verify runtime-image, framework, model, and policy counts and prerequisites.
4. Verify tenant and business authorization status.

The image shows Access Overview details. Verify the target object, current state, fields, and actions.

Open Resource Management Pages

1. Locate the target item in the operational resource checklist.
2. Click "Open" on the row.
3. After processing, return to Access Overview and refresh.

Open Authorization Management Pages

1. Locate the tenant or business authorization area.
2. Click "Manage Authorization" to open the responsible page.
3. After authorization, return and confirm that counts and status are synchronized.

Parameter Reference

Field Name	Required	Field Type	Example	Description
Connected clouds	System-generated	Number / list	Displayed on page	Shows the number and names of connected cloud platforms.
Connected resource pools	System-generated	Number / list	Displayed on page	Shows the number and names of connected resource pools.
Connected accounts	System-generated	Number / list	Displayed on page	Shows the number and names of connected accounts.
Resource	System-generated	Text	Inference images	Resource type in the operator resource checklist.
Count	System-generated	Number	Displayed on page	Number of registered or configured items under the resource type.
Prerequisites	System-generated	Text	Displayed on page	Access configurations that must be completed before the resource can be used.
Supports	System-generated	Text	Displayed on page	Describes the role of the resource in the inference deployment or scheduling flow.
Action	No	Action entry	Open	Jumps to the corresponding resource management page.
Total tenants	System-generated	Number	Displayed on page	Number of tenants in the current statistics scope.
Granted tenants	System-generated	Number	Displayed on page	Number of tenants with cloud platform grants configured.
Ungranted tenants	System-generated	Number	Displayed on page	Number of tenants without cloud platform grants configured.
Authorized resource pools	System-generated	Number / tag	Displayed on page	Number and names of resource pools available to the business type.

Pitfalls

• Do not skip the upstream dependency check: The current account can view Access Overview and its linked detail pages.
• Confirm impact before a configuration change: Use the overview to assess status. Make changes on the responsible object page and return to validate.
• A success message does not prove downstream synchronization. Use Result Validation afterward.
• Use only <API_KEY>, <PERSONAL_KEY>, <ACCESS_KEY_ID>, <ACCESS_KEY_SECRET>, <BASE_URL>, and <ENDPOINT_PATH> for credential and endpoint examples.

Result Validation

Check Item	Success Signal	If Abnormal
Page is accessible	Title, navigation, and main content display correctly	Check role permission and navigation path
Managed objects are visible	Access foundation, operational resource checklist, and authorization status display as expected	Clear filters and verify upstream dependencies
Operation result is saved	The expected state or new record appears	Review page messages, required fields, and dependencies
Downstream result is consistent	Associated pages show the change	Wait for synchronization, refresh, and return to the responsible object

FAQ

Target Object Is Missing in Access Overview

Symptom:

The expected object is missing from the list or selector.

Possible Causes:

• Active query criteria filter out the target object.
• An upstream object is disabled, or the current role lacks visibility.

Resolution:

1. Clear filters and refresh the page.
2. Verify the prerequisite object: The current account can view Access Overview and its linked detail pages.
3. Confirm the current role and data scope, then locate the object again.

Access Overview Action Is Unavailable

Symptom:

An expected button, menu, or state switch is unavailable.

Possible Causes:

• The current account lacks the required action permission.
• Object state, references, or prerequisites block the action.

Resolution:

1. Verify the permission for the action and the current object state.
2. Check references and prerequisites identified by the page message.
3. Remove the blocker, refresh the page, and perform the action once.

Access Overview Change Does Not Reach Downstream

Symptom:

The page reports success, but a downstream page still shows the old state.

Possible Causes:

• An associated page has stale cache or synchronization delay.
• The current and downstream pages use different roles, tenants, or data scopes.

Resolution:

1. Wait for synchronization and refresh both pages.
2. Confirm that both pages use the same role, tenant, and object scope.
3. If they still differ, return to the responsible object and verify the saved result.

Access Overview Data Differs from Another Page

Symptom:

Counts or states differ from an associated page.

Possible Causes:

• The pages use different filters, aggregation rules, or update times.
• The change is still synchronizing, or role-based data scopes differ.

Resolution:

1. Align filters and aggregation rules on both pages.
2. Check update times and wait for synchronization.
3. Compare object details instead of summary counts only.

How to Troubleshoot a Access Overview Failure

Symptom:

Submission fails or the state does not change for an extended period.

Possible Causes:

• Required fields, field combinations, or object state do not meet submission rules.
• An upstream dependency is invalid, the request failed, or the same action is already processing.

Resolution:

1. Record the redacted object, time, and complete page message.
2. Verify required fields, object state, and upstream dependencies.
3. Confirm that no identical job is processing before one retry.

Notes

• Use the overview to assess status. Make changes on the responsible object page and return to validate.
• Do not put real accounts, credentials, internal locations, or customer data in documentation, screenshots, tickets, or chat records.
• Authorization, deployment, deletion, publication, state, or billing changes require an auditable record and recovery plan.

Next Steps

1. Go to the cloud platform, resource pool, or access account page to complete access configuration.
2. Go to inference images, inference frameworks, model library models, or policies to view operator resource readiness.
3. Go to grant management pages to check tenant and business resource pool grants.
